BAOHUA 4.2T Two-Post Hydraulic Car Lift
A 4,200 kg two-post hydraulic vehicle lift for general repair and maintenance bays, with a 3,000 mm clear distance between the columns and 220 V or 380 V power options.
- Minimum order
- 1 set
- 4,200 kg rated lifting capacity
- Two-post layout for routine inspection and repair work
- 3,000 mm clear distance between the columns
- 2.2 kW hydraulic power unit
- 220 V or 380 V power options
Final configuration, specifications, accessories, packaging, and delivery terms are confirmed in the quotation.
Product overview
BAOHUA's 4.2T floor plate type two-post hydraulic car lift offers a 4,200 kg rated capacity for independent repair workshops, dealership service bays and underbody maintenance. Its electric-hydraulic drive uses a 2.2 kW power unit with 220 V or 380 V supply options. The layout provides 3,000 mm clear spacing between columns, a 2,730 mm drive-through width and a minimum pad height of 110 mm.
Overall width is 3,530 mm. Use these dimensions to plan vehicle access and bay spacing, and confirm support-point compatibility, concrete foundations, anchors, ceiling clearance and electrical phase before installation.
TECHNICAL DATA
Specifications
Values below follow the supplied product listing. Confirm the final selected configuration before ordering.
Product specifications
| Lift type | Floor plate type two-post lift |
|---|---|
| Lifting capacity | 4,200 kg |
| Minimum pad height | 110 mm |
| Motor power | 2.2 kW |
| Power supply | 220 V / 380 V |
| Drive | Electric-hydraulic |
| Overall width | 3,530 mm |
| Clear distance between columns | 3,000 mm |
| Drive-through width | 2,730 mm |
Installation requirements
Confirm the concrete foundation, anchor layout, ceiling clearance, electrical phase, frequency, and local installation requirements before ordering.
Packaging information
- Packaging dimensions
- 2,960 × 535 × 820 mm
- Gross weight
- 545 kg
PRODUCT DETAILS
Features, construction, and applications
Review the available product detail images for the selected equipment.
View 6 more detail images
PRODUCT VIDEO
See the equipment in detail
Play the product video directly on this page.
MODEL SELECTION
How to choose this equipment
Selection guidance
- Common two-post lift search terms
- This equipment is a 4.2T floor plate type two-post hydraulic car lift with a connecting plate at floor level. It is also described as a 4200 kg floor-plate vehicle lift, 2 post car lift, automotive hoist, or workshop garage lift.
- Two-post car lift dimensions
- For site planning, compare the 3,530 mm overall width, 3,000 mm clear distance between columns, 2,730 mm drive-through width, and 110 mm minimum pad height with the service bay. Confirm ceiling clearance using the installation drawing for this floor plate model.
BUYER SEARCH GUIDE
Floor plate two-post lift sourcing guide
This floor plate type two-post hydraulic lift is intended for compatible general repair, underbody inspection, suspension work and vehicle maintenance bays.
Common sourcing language
Importers, distributors, and workshop buyers may describe BAOHUA 4.2T Two-Post Hydraulic Car Lift using these related terms:
- 4.2 ton floor plate two-post lift
- 4200 kg two-post car lift
- base-plate vehicle lift
- hydraulic car hoist
What to compare before ordering
This model uses a floor plate connecting the columns at ground level. Compare rated capacity, column spacing, lifting height, vehicle lifting points, power supply and concrete requirements. Allow for the floor plate when planning vehicle access and movement around the service bay.
View Car Lifts
Compare related models and choose the configuration that matches your vehicles, process, utilities, and workshop layout.
View categoryBUYER FAQ
4.2T two-post car lift FAQ
Review the confirmed product data and the project information needed before requesting a final configuration.
What is the rated capacity of this two-post car lift?
The stated rated lifting capacity is 4,200 kg. Vehicle weight distribution and approved lifting points still need to be checked for each vehicle.
What is the clear distance between the lift columns?
The supplied specification states a 3,000 mm clear distance between the columns and a 2,730 mm drive-through width.
Which power supply can be selected?
The product listing states 220 V or 380 V options with a 2.2 kW hydraulic power unit. Final voltage and frequency should be confirmed for the destination.
Which workshops commonly review this lift?
The page lists independent repair workshops, dealership service bays, vehicle inspection, and underbody maintenance applications.
What installation information is needed for a quotation?
Provide vehicle types, maximum vehicle weight, bay width, ceiling height, foundation information, power supply, and destination.
Should a low-rise scissor lift also be considered?
A low-rise scissor lift may be reviewed for tire and quick-service work where full underbody access or a two-post layout is not required.
Planning your two-post lift purchase
Use the two-post lift selection guide to prepare your vehicle and workshop requirements.
Review workshop space requirements and the voltage, phase and frequency checklist before confirming the installation.
Compare the published 4.2T, 5T and 6T model specifications when planning your service bay.
