BAOHUA EC500 5T 45° Asymmetric Two-Post Car Lift
Model: EC500
A 5,000 kg overhead two-post hydraulic lift with 45-degree asymmetric columns for passenger-vehicle repair bays, a 1,800 mm lifting height, and multi-voltage power options.
- Minimum order
- 1 set
- 5,000 kg rated lifting capacity
- 45-degree asymmetric two-post layout
- Overhead clear-floor configuration
- 1,800 mm maximum lifting height and 90 mm minimum height
- 110 V, 220 V, or 380 V power options
Final configuration, specifications, accessories, packaging, and delivery terms are confirmed in the quotation.
Product overview
The BAOHUA EC500 is a 5,000 kg two-post hydraulic car lift with 45-degree asymmetric columns and an overhead clear-floor layout for passenger-vehicle repair bays. It offers a maximum lifting height of 1,800 mm, a 90 mm minimum height and a 2.2 kW motor. Power options are 110 V, 220 V or 380 V, selected for the workshop supply.
Applications include dealership servicing, vehicle inspection and underbody maintenance. Plan the concrete foundation, anchors and ceiling clearance around the 3,720 mm overall structure, and confirm electrical phase before ordering.
The EC500 drawing specifies 3,500 mm overall width in plan view, a separate 3,260 mm upper width in front view, 2,840 mm clear distance between columns and 2,500 mm drive-through width. The 45-degree asymmetric layout provides space for vehicle-door opening and entry or exit; actual clearance depends on vehicle dimensions and positioning.
The lift uses a VIBO hydraulic power unit, metal hydraulic oil pipes, a maintenance-free steel cable design, single-side manual lock release and automatic arm locking. The maintenance-free description applies to the steel cable, not the complete lift; follow the operating manual for routine inspections and equipment maintenance.
Vehicle applications cover sedans, sports cars, SUVs, MPVs, pickups, electric vehicles and hybrids that meet the 5,000 kg rated capacity, load-distribution, lifting-point, ground-clearance and arm-reach requirements. Check each vehicle before lifting.
The EC500 is CE certified and is supplied through ISO 9001-certified manufacturing. Warranty coverage is 3 years for the complete lift and 10 years for the steel cable.
Manufacturer production and workshop examples include laser cutting, bending, robotic welding, powder coating, multi-bay workshop installations and export packing and container loading. These examples describe the manufacturer's production and application capabilities; model selection remains specific to the customer's vehicles and workshop.
Net weight is 660 kg and gross shipping weight is 680 kg. The package measures 3,700 × 620 × 580 mm, approximately 1.33 m³. Packaging length is separate from the lift's 3,720 mm installed overall height.
TECHNICAL DATA
Specifications
Values below follow the supplied product listing. Confirm the final selected configuration before ordering.
Product specifications
| Model | EC500 |
|---|---|
| Lift type | Overhead two-post hydraulic lift |
| Lifting capacity | 5,000 kg |
| Maximum lifting height | 1,800 mm |
| Minimum height | 90 mm |
| Lifting time | 55 s |
| Column layout | 45° asymmetric |
| Arm locking | Automatic arm locking system |
| Motor power | 2.2 kW |
| Power supply | 110 V / 220 V / 380 V |
| Hydraulic power unit | VIBO |
| Net weight | 660 kg |
| Overall height | 3,720 mm |
| Overall width | 3,500 mm |
| Front-view upper width | 3,260 mm |
| Clear distance between columns | 2,840 mm |
| Drive-through width | 2,500 mm |
| Lock release | Single-side manual release |
| Hydraulic lines | Metal hydraulic oil pipes |
| Steel cable | Maintenance-free design |
| Product certification | CE |
| Manufacturing quality management | ISO 9001 |
Installation requirements
Confirm the concrete foundation, anchor layout, safe ceiling clearance above the 3,720 mm structure, electrical phase, and local installation requirements before ordering.
Packaging information
- Packaging dimensions
- 3,700 × 620 × 580 mm
- Packing volume
- 1.33 m³
- Gross weight
- 680 kg
Commercial information
Warranty: 3-year warranty for the complete lift; 10-year warranty for the steel cable.
PRODUCT DETAILS
Features, construction, and applications
Review the available product detail images for the selected equipment.
View 14 more detail images
MODEL SELECTION
How to choose this equipment
Selection guidance
- EC500 installation dimensions
- Use the EC500 drawing values: 3,720 mm overall height, 3,500 mm plan-view overall width, 3,260 mm front-view upper width, 2,840 mm clear column spacing and 2,500 mm drive-through width. Allow additional vehicle and working clearance.
- Vehicle compatibility and asymmetric layout
- Check the vehicle against the 5,000 kg rating, arm reach, approved lifting points, ground clearance and load distribution. Review door opening and access around the 45-degree asymmetric columns.
- Operation and support
- Single-side manual release and automatic arm locking support the workshop operating process. The complete lift has a 3-year warranty and the steel cable a 10-year warranty. Follow the manual for routine inspection and maintenance.
BUYER SEARCH GUIDE
Two-post vehicle lift sourcing guide
This equipment is commonly sourced for general repair, underbody inspection, suspension work, wheel service, and vehicle maintenance bays.
Common sourcing language
Importers, distributors, and workshop buyers may describe BAOHUA EC500 5T 45° Asymmetric Two-Post Car Lift using these related terms:
- two-post car lift
- 2 post vehicle lift
- hydraulic car hoist
- clear-floor workshop lift
What to compare before ordering
When comparing a two-post car lift, buyers normally check rated capacity, clear-floor or base-plate layout, column spacing, lifting height, release method, power supply, concrete requirements, and car lift size in mm. Match these points to the heaviest vehicle and the available workshop bay before ordering.
View Car Lifts
Compare related models and choose the configuration that matches your vehicles, process, utilities, and workshop layout.
View categoryBUYER FAQ
EC500 asymmetric two-post lift FAQ
Review the confirmed product data and the project information needed before requesting a final configuration.
What lifting capacity is stated for the EC500?
The supplied specification states a lifting capacity of 5,000 kg.
What lifting height is listed?
The source data lists a maximum lifting height of 1,800 mm.
What minimum height is stated?
The supplied specification states a minimum height of 90 mm.
What does the 45-degree layout refer to?
The source listing describes a 45-degree asymmetric column layout. Vehicle fit and door clearance should be checked for the intended fleet.
What power configuration is listed?
The product data states a 2.2 kW motor with 110 V, 220 V, or 380 V power options.
What width dimensions should I use for the EC500?
The EC500 drawing gives 3,500 mm overall width in plan view, 3,260 mm upper width in front view, 2,840 mm clear spacing between columns and 2,500 mm drive-through width. These dimensions refer to different measuring positions; allow additional working clearance.
Which vehicles can the EC500 lift?
Applications include sedans, sports cars, SUVs, MPVs, pickups, electric vehicles and hybrids within the 5,000 kg rating. Compatibility also depends on load distribution, manufacturer-approved lifting points, ground clearance and arm reach; check each vehicle before use.
How are the locks released and the arms secured?
The EC500 uses single-side manual lock release and an automatic arm locking system. Follow the operating manual for positioning, locking and lowering the lift.
What warranty is provided?
The complete lift has a 3-year warranty. The steel cable has a separate 10-year warranty.
Does maintenance-free steel cable mean the entire lift needs no maintenance?
No. Maintenance-free describes the steel cable design only. Routine safety inspections and maintenance of the lift remain necessary in accordance with the operating manual.
What are the EC500 shipping dimensions and weights?
Packaging dimensions are 3,700 × 620 × 580 mm, approximately 1.33 m³. Net weight is 660 kg and gross weight is 680 kg. The 3,700 mm package length is separate from the 3,720 mm installed lift height.
What certification and manufacturing information is available?
The EC500 is CE certified, and manufacturing is covered by ISO 9001 quality management certification. Manufacturer examples include laser cutting, bending, robotic welding, powder coating, workshop installations and export loading.
What information is needed for a quotation?
Provide vehicle range, bay and ceiling dimensions, slab details, power supply, arm and release requirements, quantity, and destination.
Planning your two-post lift purchase
Use the two-post lift selection guide to prepare your vehicle and workshop requirements.
Review workshop space requirements and the voltage, phase and frequency checklist before confirming the installation.
Check the arm reach and vehicle-fit checklist against the vehicles you service.
